IOT Based Servo Voltage Stabilizer

Rating : 1KVA to 500KVA

Rating: Air-cooled voltage stabilizer up to 100kVA. Oil cooled voltage stabilizer up to 1000kVA.

What is Servo Voltage Stabilizer?

A servo voltage stabilizer is a stabilizer which constantly monitors the output voltage and controls variations in the input voltage by the movements of a motor. In other words, it automatically regulates the voltage. This motor decides the output voltage on the transformer. It is considered to be a cheap and good voltage stabilizer. This is a perfect solution to protect the appliances from voltage fluctuations. Enertech India the leaders in voltage stabilizer manufacturers, offers advanced micro controller based voltage stabilizers.

What is the Importance of Servo Voltage Stabilizer?

A stabilizer is highly important for optimum performance of any electrical or electronic equipment that maintains input mains voltage stability. A fluctuation, be it a high voltage or low voltage can prove harmful on the voltage-sensitive devices. Hence, a solution has been identified by servo stabilizer manufacturers that will guarantee that the voltage will be under the safety limits. The stabilizer ensures that the load is operated within safety limits and machines operate at a better efficiency avoiding losses.

Enertech is the premier voltage stabilizer manufacturers in Pune & Mumbai offers specially designed solutions. These solutions are created using the advanced microcontroller in which the voltage stabilizer provides precise and accurate correction with a feature of auto-calibration. As innovative servo stabilizer manufacturers in India, we have been employing an instant response system using a feedback mechanism to enhance the correction of automatic voltage stabilizer.

Why Enertech's Servo Voltage Stabilizer?

Enertech as leading servo stabilizer manufacturers based in Pune and Mumbai offers stabilizers that have user-friendly keypads and dashboard status to read input and output parameters. These voltage stabilizers are indigenously manufactured and supplied in Mumbai and Pune.

We have been the servo stabilizer manufacturer who offers technologically enhanced and important indication features like mains ON, overload, over-voltage, under-voltage trip, output ON and single phasing.

We have been accredited as one of the best voltage stabilizer manufacturers, for voltage stabilizers having features like

  • The stabilizer offers rugged, smooth as well as high-speed voltage correction
  • It has a user-friendly dashboard and 97% high efficiency
  • The designed is based on Microcontroller
  • It has a quick response time of 10 sec
  • This voltage stabilizer has phase reversal, short circuit, and overload protection.
  • Also equipped with manual adjustment of voltage using a potentiometer and a high regulation up to +/-0.5%
  • These stabilizers are small and compact in size.

Applications

  • Medical equipment
  • CNC & machine tools
  • Telecom equipment
  • Air conditioners
  • Knitting machines
  • Printing machines
  • Welding machines
  • Other sophisticated equipment

Range 170V - 270V

Rating 1KVA - 25KVA
Input Voltage 170 V to 270V, 1 Phase, 50Hz, Unbalance
Input frequency 47 Hz TO 53 Hz
Output Voltage 230V ± 1%, 1 Phase, 50Hz, Balance
Voltage Regulation ± 1%
Motorization AC Motor
Efficiency Better Than 98%
Cooling Air Cooled
Waveform distortion Nil
Rate of Corrections Usually 25V/Sec/Phase but depends on rating.
O/P Voltage Adjustment by means of Potentio Meter.
Controls Auto / Manual.
Protection /Specification Under voltage cutoff

Over voltage cutoff

Short Circuit Protection

Overload Protection

Single phase preventer

Phase reversal

Indication Mains ON, O/P ON, O/V, U/V Single Phasing Trip.
It will be suitable for both Balance and Unbalanced load.
Cable of length 5 meters along with connector will be provided.
Documentation: The following documents will be provided by the supplier along with the equipment:

·        User Manual.

·        Warranty Certificate for a period of minimum 1 year from the date of acceptance.

DSP features: ( Optional )

·        Remote controlled feature :

ON/OFF of stabilizer

·        Settings of input / output high/low cut off and setting of overload

·        Summary of Input & Output voltage / current on server

·        Communication Port – RS 485 Modbus

Range 360V - 470V

Rating (3PH-3PH) 5KVA - 500KVA
Input Voltage 360 V to 470V, 3 Ph, 4 Wires, 50 Hz, Unbalance
Input frequency 47 Hz TO 53 Hz
Output Voltage 415V ± 1%, 3 Phase, 4 Wires, 50Hz, Balance
Voltage Regulation ± 1%
Motorization AC Motor
Efficiency Better Than 98%
Cooling Oil Cooled / Air Cooled
Waveform distortion Nil
Rate of Corrections Usually 25V/Sec/Phase but depends on rating.
O/P Voltage Adjustment By means of Potentio Meter.
Controls Auto / Manual.
Protection /Specification Under voltage cutoff

Over voltage cutoff

Short Circuit Protection

Overload Protection

Single phase preventer

Phase reversal

Indication Mains ON, O/P ON, O/V, U/V Single Phasing Trip.
It will be suitable for both Balance and Unbalanced load.
Cable of length 5 meters along with connector will be provided.
Documentation: The following documents will be provided by the supplier along with the equipment:

·        User Manual.

·        Warranty Certificate for a period of minimum 1 year from the date of acceptance.

DSP features: ( Optional )

·        Remote controlled feature :

ON/OFF of stabilizer

·        Settings of input / output high/low cut off and setting of overload

·        Summary of Input & Output voltage / current on server

·        Communication Port – RS 485 Modbus
